ASRock B650 Steel Legend Wi-Fi AM5 DDR5 ATX Motherboard

Unique Feature	Superb Productivity
	- PCIe Gen5 (Graphics, M.2)
	- Dual Channel DDR5
	Rock-Solid Durability
	- 14+2+1 Power Phase, 80A Dr.MOS with Enlarged Heatsink Armor
	- Flexible Integrated I/O Shield
	- 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)
	Ultrafast Connectivity
	- 2.5G LAN, 802.11axe Wi-Fi 6E Module
	EZ Update
	- BIOS Flashback Button
	- ASRock Auto Driver Installer
	EZ Troubleshooter
	- ASRock Post Status Checker
CPU	- Supports AMD Socket AM5 Ryzen™ 8000 and 7000 Series Processors*
	*The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details.
Chipset	- AMD B650
Memory	- Dual Channel DDR5 Memory Technology
	- 4 x DDR5 DIMM Slots
	- Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)
	- Max. capacity of system memory: 192GB
	- Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
BIOS	- 256Mb AMI UEFI Legal BIOS with GUI support
Graphics	Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
	- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
	- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz
Audio	- 7.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)
	- Individual PCB Layers for R/L Audio Channel
	- Impedance Sensing on Rear Out port
	- Nahimic Audio
LAN	- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
	- Dragon RTL8125BG
	- Supports Dragon 2.5G LAN Software
	- Smart Auto Adjust Bandwidth Control
	- Visual User Friendly UI
	- Visual Network Usage Statistics
	- Optimized Default Setting for Game, Browser, and Streaming Modes
	- User Customized Priority Control
Wireless LAN	- 802.11axe Wi-Fi 6E Module
	- Supports IEEE 802.11a/b/g/n/ac/ax/axe
	- Supports Dual-Band 2x2 with extended 6GHz band* support
	- 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
	- Supports Bluetooth 5.2 + High speed class II
	- Supports MU-MIMO
	* Wi-Fi 6E (6GHz band) will be supported by Microsoft Windows® 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows® Update and software updates once available.
	A 6GHz compatible router is required for 6E functionality.
Slots	CPU:
	- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
	Chipset:
	- 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode*
	- 1 x PCIe 4.0 x1 Slot (PCIE3)*
	- 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
	- Supports AMD CrossFire™
	- 15μ Gold Contact in VGA PCIe Slot (PCIE1)

	* Supports NVMe SSD as boot disks
	If SATA3_0 and SATA3_1 are occupied, PCIE2 will downgrade to x2 mode.
Storage	CPU:
	- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode*
	- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset:
	- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
	- 2 x SATA3 6.0 Gb/s Connectors**
	ASMedia ASM1061:
	- 2 x SATA3 6.0 Gb/s Connectors

	* Supports NVMe SSD as boot disks
	** If SATA3_0 and SATA3_1 are occupied, PCIE2 will downgrade to x2 mode.
RAID	- Supports RAID 0 and RAID 1 for SATA storage devices
	- Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*

	* Requires additional M.2 NVMe expansion cards to support RAID 10
USB	CPU:
	- 1 x USB 3.2 Gen2 Type-A (Rear)
	- 2 x USB 3.2 Gen1 Type-A (2 Rear (USB32_12)) Chipset:
	- 1 x USB 3.2 Gen2x2 Type-C (Rear)
	- 1 x USB 3.2 Gen1 Type-C (Front)
	- 6 x USB 3.2 Gen1 Type-A (2 Rear (USB32_34), 4 Front)
	- 8 x USB 2.0 (4 Rear, 4 Front)

	* All USB ports support ESD Protection
Connector	- 1 x SPI TPM Header
	- 1 x Power LED and Speaker Header
	- 1 x RGB LED Header*
	- 3 x Addressable LED Headers**
	- 1 x CPU Fan Connector (4-pin)***
	- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
	- 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
	- 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
	- 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
	- 1 x Front Panel Audio Connector
	- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
	- 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
	- 1 x Front Panel Type C USB 3.2 Gen1 Header

	* Supports in total up to 12V/3A, 36W LED Strip
	** Support in total up to 5V/3A, 15W LED Strip
	*** CPU_FAN1 supports the fan power up to 1A (12W).
	**** CPU_FAN2/WP supports the fan power up to 2A (24W).
	***** CHA_FAN1~4/WP support the fan power up to 2A (24W).
	***** CPU_FAN2/WP and CHA_FAN1~4/WP can auto detect if 3-pin or 4-pin fan is in use.
Rear Panel I/O	- 2 x Antenna Ports
	- 1 x HDMI Port
	- 1 x DisplayPort 1.4
	- 1 x Optical SPDIF Out Port
	- 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
	- 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)
	- 4 x USB 3.2 Gen1 Type-A Ports (USB32_34 support Ultra USB Power.)
	- 4 x USB 2.0 Ports
	- 1 x RJ-45 LAN Port
	- 1 x BIOS Flashback Button
	- 1 x Line Out Jack (Gold Audio Jack)
	- 1 x Microphone Input Jack (Gold Audio Jack)
Software and UEFI	Software
	- ASRock Motherboard Utility (A-Tuning)
	- ASRock Dragon 2.5G LAN Software
	- ASRock Polychrome SYNC*
	UEFI
	- ASRock Full HD UEFI
	- ASRock Auto Driver Installer
	- ASRock Instant Flash

	*These utilities can be downloaded from ASRock Live Update & APP Shop.
Accessories	- 1 x User Manual
	- 2 x SATA Data Cables
	- 2 x ASRock WiFi 2.4/5/6 GHz Antennas
	- 3 x Screws for M.2 Sockets
	- 1 x Standoff for M.2 Socket
Form Factor	- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
	- 8 Layer PCB
OS	- Microsoft Windows® 10 64-bit / 11 64-bit
Certifications	- FCC, CE
	- ErP/EuP ready (ErP/EuP ready power supply is required)
